TDA1200/TDA1600 Aerator

TDA1200/TDA1600 Aerator

Models
TDA1600, TDA1200

The Baroness TDA1200/1600 tractor mounted Aerator is another quality machine from Kyoeisha Co. Ltd. of Japan which combines sturdiness, efficiency and simplicity to give you absolutely the best possible finish on golf greens, sports pitches and playing fields.

Related Categories

Agriculture
Agriculture
:
Specialist Turf Equipment
Golf and Turf
Golf and Turf
:
Specialist Turf Equipment
Contact Us

Documents

Download BrochureTDA1200-TDA1600 Aerator Operator's Manual
Turf aerator attachment with rows of coring tines.
Turf aerator attachment with rows of coring tines on a white studio background.
No items found.

Features

Adaptable Aeration Control

Flexible aeration performance with tool-free depth adjustment, multiple tine options and a two-speed gearbox that allows operators to vary hole spacing and suit different turf management programs.

Low Power, Turf-Safe

Lightweight, turf-friendly design requiring just 17.7 hp (TDA1200) or 23.6 hp (TDA1600) minimum tractor power, reducing ground pressure and making it ideal for greens, tees, bowling greens, tennis courts and sports turf.

Stronger Roots, Cleaner Finish

Deep and effective aeration with a working depth of up to 250 mm (TDA1200) or 180 mm (TDA1600), helping relieve compaction, improve drainage and promote stronger root growth in high-traffic turf areas. Excellent post-aeration presentation thanks to a full-width rear roller, roller scraper and soil reliever finger plates that minimise turf lifting and leave a smooth, professional finish.

Key Specifications

{"version":1,"models":[{"code":"TDA1600"},{"code":"TDA1200"}],"sections":[{"name":"Specifications","rows":[{"label":"Length","values":["970 mm","970 mm"]},{"label":"Width","values":["1790 mm","1420 mm"]},{"label":"Height","values":["850 mm","850 mm"]},{"label":"Weight","values":["580 kg","495 kg"]},{"label":"Working Width","values":["1560 mm","1170 mm"]},{"label":"Depth","values":["180 mm","250 mm"]},{"label":"Spacing","values":["65 – 100 mm","62 – 100 mm"]},{"label":"PTO Speed","values":["540 / 1000","540 / 1000 rpm"]},{"label":"Work Rate","values":["3120 m2/h","2600 m2/h"]}]},{"name":"Drive Train","rows":[{"label":"Transmission","values":["2-speed Gearbox","2-speed Gearbox"]},{"label":"Tractor Power Min.","values":["17.6 kW","13.2 kW"]}]}]}
