Auger Drive SA20 Series
Models
SA20
The SA20 is ideal for landscapers, contractors, construction companies, farmers, ranchers, and others.
Related Categories
No items found.
Features
Hydraulic hoses
Hydraulic hoses are routed out the top of the gearbox housing, allowing housing to follow auger into a deeper hole without damaging hoses.
Level indicator
Patented level indicator makes it easy to know when the auger is vertical to drill straight holes
Offset mount
The Skid Augers have a center and 18" offset mount to the right to adjust drill position.
Key Specifications
{"version":1,"models":[{"code":"SA20"}],"sections":[{"name":"Auger Drive Specifications","rows":[{"label":"Min. Hydraulic Flow","values":["23 l/min"]},{"label":"Max. Hydraulic Flow","values":["57 l/min"]},{"label":"Base Weight w/o Options","values":["20.8 kg"]},{"label":"Max. Auger Speed","values":["110 rpm"]},{"label":"Gearbox","values":["Hydraulically Driven Planetary"]},{"label":"Gearbox Oil Capacity","values":["414 mL"]},{"label":"Hitch","values":["Universal Quick Attach"]},{"label":"Hydraulic Hose Length","values":["2.4 m"]},{"label":"Hydraulic Couplers","values":["Male Pioneer"]}]},{"name":"Auger Specifications","rows":[{"label":"Auger Flighting Thickness","values":["8 mm"]},{"label":"Auger Teeth","values":["Forged"]},{"label":"Auger Length","values":["1.29 m"]},{"label":"Min. Dirt Auger Size","values":["6\" (152mm)"]},{"label":"Max. Dirt Auger Size","values":["36\" (914mm)"]},{"label":"Min. Rock Auger Size","values":["6\" (152mm)"]},{"label":"Max. Rock Auger Size","values":["24\" (610mm)"]},{"label":"Short Auger Extension","values":["24\" (610mm)"]},{"label":"Long Auger Extension","values":["48\" (1219mm)"]}]}]}
