Folding Rotary Cutters

Models

RC2512-2, RC(G)3715, RC(M)5715, RC(M)4620

The Land Pride range of folding rotary cutters includes models with working width from 12ft (3.6m) to 20ft (6.1m). The RC2512-2 has a 12ft (3.7m) working width and is suitable for 40-100hp tractors, The RC2512-2 has a 1.5" (38mm) cut capacity making it ideal for pasture maintenance and similar light duty tasks. The RC37 series includes a 15ft (4.6m) working width model and is our most popular series. The RC37 series is highly versatile and heavy duty with a 3" (75mm) cut capacity. The RC37 series is available with our standard painted finish or a galvanise dipped finish (RCG37 series). The galvanised model has all of the same great features as its painted counterpart. The only difference being the galvanised finish with 10 year rust through deck warranty. The RC57 series is a heavy duty series most commonly purchased by roadside mowing contractors, intensive users or customers looking for our most robust and durable 15ft (4.6m) folding rotary cutter. The RC57 series is available in 540 or 1,000rpm PTO speed and has an impressive 5" (125mm) cut capacity. The RC46 series includes a 20ft (6.1m) working width model and is commonly used for wide area mowing applications like airports and air force bases. The RC46 series is available in 540 or 1,000rpm PTO speed and has a 3" (75mm) cut capacity.

Related Categories

Documents

Download Brochure

No items found.

Features

GEARBOX WARRANTY

5 year limited gearbox warranty on RC25 & RC37 series. 7 year limited gearbox warranty on RC57 & RC46 series. This industry leading warranty shows our confidence in gearbox integrity.

LED SIGNAL LIGHTS

LED lights are bright, long lasting and resistant to vibration, unlike the incandescent lights.

BEVELED SKID SHOES

Wing skid shoes are flanged up along length of outside edge. This allows operator to turn without leading edge of wing skid shoes digging into the ground.

Sliding centre shield

Sliding centre shield offers ease-of maintenance for slip-clutches and U-joints.

Optional dual wing wheels

Dual wing wheels are optional on most models for improved flotation and ground following

Key Specifications

{"version":1,"models":[{"code":"RC2512-2"},{"code":"RC(G)3715"},{"code":"RC(M)5715"},{"code":"RC(M)4620"}],"sections":[{"name":"Specifications","rows":[{"label":"Min. Horsepower","values":["40 hp","50 hp","50 hp","70 hp"]},{"label":"Max. Horsepower","values":["100 hp","160 hp","250 hp","250 hp"]},{"label":"Safety Guards, Front & Rear","values":["Chain","Chain","Chain","Chain"]},{"label":"Gearbox Rating - Divider","values":["160 hp","160 hp","250 hp","250 hp"]},{"label":"Gearbox Rating - Center & Wings","values":["100 hp","130 hp","210 hp","210 hp"]},{"label":"PTO Speed","values":["540 rpm","540 rpm","540 rpm","540 rpm"]},{"label":"Tyre Type - Used Aircraft Tyres","values":["Yes","Yes","Yes","Yes"]},{"label":"Galvanised Finish Option","values":["Not Available","Available","Not Available","Not Available"]}]},{"name":"Hitch","rows":[{"label":"Land Pride Performance Self-Levelling","values":["Yes","Yes","Yes","Yes"]}]},{"name":"Dimensions","rows":[{"label":"Working Width","values":["3.7 m","4.6 m","4.6 m","6.1 m"]},{"label":"Overall Width","values":["384 cm","483 cm","478 cm","636 cm"]},{"label":"Overall Length","values":["404 cm","495 cm","488 cm","540 cm"]},{"label":"Min. Cutting Height","values":["38 mm","38 mm","","50 mm"]},{"label":"Max. Cutting Height","values":["300 mm","406 mm","","300 mm"]},{"label":"Deck Thickness","values":["3.4 mm","3.4 mm","Top 10 Gauge (3.4mm) Bottom 3/16\" (5mm)","3.4 mm"]},{"label":"Cutting Capacity - Diameter","values":["38 mm","75 mm","125 mm","76 mm"]},{"label":"Deck Height","values":["279 mm","300 mm","300 mm","330 mm"]},{"label":"Weight","values":["1152 kg","1987 kg","2470 kg","2849 kg"]},{"label":"Dishpan","values":["Yes","Yes","Yes","Yes"]},{"label":"Min. Transport Width / with Narrow Option","values":["","312 / 221 cm","",""]},{"label":"Min. Cutting height","values":["","","50 mm",""]},{"label":"Max. Cutting height","values":["","","355 mm",""]},{"label":"Min. Transport Width","values":["","","","302 cm"]}]},{"name":"Blades","rows":[{"label":"Blade Length","values":["75 mm","100 mm","100 mm","100 mm"]},{"label":"Blade Width","values":["13 mm","13 mm","13 mm","13 mm"]},{"label":"Blade Tip Speed 540 - Centre","values":["83.8 mps","","",""]},{"label":"Blade Tip Speed 540 - Wings","values":["81.3 mps","76.2 mps","83 mps","86.4 mps"]},{"label":"Blade Tip Speed 1000 - Centre","values":["N/A","","",""]},{"label":"Blade Tip Speed 1000 - Wings","values":["N/A","N/A","81.3 mps","91.4 mps"]},{"label":"Shredder Kit","values":["N/A","N/A","Optional","Optional"]},{"label":"Blade Tip Speed 540 - Center","values":["","77.6 mps","83 mps","86.4 mps"]},{"label":"Blade Tip Speed 1000 - Center","values":["","N/A","83 mps","91.4 mps"]}]}]}
