Grading Scraper GS15 Series

Models

GS1548, GS1560, GS1572

Land Pride's GS15 Series Grading Scrapers have uses in applications such as landscaping, small farms, large estates and small acreages. The GS15 Series is also extra user-friendly and a low cost alternative for road grading applications. Unlike a box scraper, they are not designed to transfer large volumes of dirt from one location to another and as a result do not require the additional horsepower that a box scraper normally requires. Nor does it require the tending of tractor 3-point lift controls to maintain grade that a box scraper might require.

Related Categories

Documents

Download Brochure GS15 Grading Scraper Operator's Manual

No items found.

Features

QUICK-HITCH COMPATIBLE

Cat. 1 & Cat. 1 Quick-Hitch compatible. Has lower hitch clevis type mountings. Makes for faster and easier hookup to the tractor. Our Quick-Hitch System allows you to quickly connect and disconnect from the implement - most without leaving the tractor seat. This is a real time saver when working on multiple projects.

HARDENED TIPS

Hardened tips on scarifier shanks assure long service life.

GRADING BLADES

Reversible, heat-treated, high-carbon steel grading blades offer excellent wear resistance and long service life.

SKID SHOES

Replaceable and reversible full length skid shoes make for easier operation and long unit life.

ADJUSTABLE HEIGHT

Dual, adjustable height grading blades and optional 4-position scarifier shanks allow the scraper to be adjusted to desired amount of cultivation, leveling, and grading action.

Key Specifications

{"version":1,"models":[{"code":"GS1548"},{"code":"GS1560"},{"code":"GS1572"}],"sections":[{"name":"Specifications","rows":[{"label":"Min. Horsepower","values":["20 hp","25 hp","25 hp"]},{"label":"Max. Horsepower","values":["50 hp","50 hp","50 hp"]},{"label":"Hitch - Cat I","values":["Yes","Yes","Yes"]},{"label":"Working Width","values":["122 cm","152 cm","184 cm"]},{"label":"Side Panel Thickness","values":["4.7 mm","4.7 mm","4.7 mm"]},{"label":"Skid Shoe Thickness","values":["10 mm","10 mm","10 mm"]},{"label":"Number of Shank Positions","values":["4","4","4"]},{"label":"Cutting Edge Width","values":["152 mm","152 mm","152 mm"]},{"label":"Cutting Edge Thickness","values":["12.7 mm","12.7 mm","12.7 mm"]},{"label":"Cutting Edge Adjustment","values":["Adjustable","Adjustable","Adjustable"]},{"label":"Weight","values":["198 kg","232 kg","269 kg"]}]}]}
