Grooming Mowers FDR25 Series

Models

FDR2572, FDR2584

Land Pride's FDR25 Series Grooming Mowers offer the same 3-blade system and floating hitch as the FDR16 and provide professional results for larger acreage homeowners and municipalities. Their frame-over-deck design supports the deck, minimizing flex and provides superb cutting performance in turf-grass applications.

Related Categories

Documents

Download Brochure Features & Benefits

No items found.

Features

Discharge

The wide, even dispersal of grass leaves a fine thin layer directly behind the mower, vs. a possible windrow to the side. Keeps grass from blowing in unwanted areas. Easier to mow around objects.

Floating 3-point

Top and bottom hitch points float up and down which allows the mower to float over uneven terrain.

Non-aligned gauge wheels

Rear wheels don't track behind the front wheels to reduce laying grass over.

Solid rubber tires

Solid rubber tires (only on the FDR2572) are sandwiched between the rim halves, bolted in, and can't go flat. Roller bearings allow for a long life.

Key Specifications

{"version":1,"models":[{"code":"FDR2572"},{"code":"FDR2584"}],"sections":[{"name":"Specifications","rows":[{"label":"Horsepower","values":["15-60 hp","15-60 hp"]},{"label":"Weight","values":["326 kg","368 kg"]},{"label":"Discharge","values":["rear","rear"]},{"label":"Deck Material Thickness","values":["3/16 \"","3/16 \""]},{"label":"Front roller","values":["Optional","Optional"]}]},{"name":"Dimensions","rows":[{"label":"Working Width","values":["183 cm","213 cm"]},{"label":"Overall Width","values":["190 cm","220 cm"]},{"label":"Cutting Height (min)","values":["3/4 \"","3/4 \""]},{"label":"Cutting Height (max)","values":["5-1/4","5-1/4"]}]},{"name":"Hitch","rows":[{"label":"Hitch","values":["Cat. 1","Cat. 1"]},{"label":"Lower Hitch","values":["Floating clevis w/ plated pins","Floating clevis w/ plated pins"]},{"label":"Top link","values":["Floating clevis","Floating clevis"]}]},{"name":"Blades","rows":[{"label":"Blade thickness","values":["1/4 \"","5/16 \""]},{"label":"Blade width","values":["2-1/2 \"","2-1/2 \""]},{"label":"Blade length","values":["25 \"","29 \""]},{"label":"Blade material","values":["Heat treated alloy steel","Heat treated alloy steel"]},{"label":"Blade overlap","values":["1-1/4 \"","1-1/4 \""]},{"label":"Blade spindles","values":["Greaseable","Greaseable"]},{"label":"Deck spindle housings","values":["Cast iron greaseable hubs","Cast iron greaseable hubs"]},{"label":"Blade tip speed","values":["18130 fpm","17210 fpm"]}]},{"name":"Tyres","rows":[{"label":"Number of wheels","values":["4","4"]},{"label":"Wheel type","values":["Castered gauge wheel","Castered gauge wheel"]},{"label":"Tire material","values":["Solid rubber","Semi-solid"]},{"label":"Wheel (width)","values":["3-1/4 \"","4 \""]},{"label":"Wheel (height)","values":["10 \"","11 \""]},{"label":"Castered Wheel Spindle (diameter)","values":["1 \"","1 \""]}]},{"name":"Drive Train","rows":[{"label":"Speed","values":["540 rpm","540 rpm"]},{"label":"Section","values":["B","B"]},{"label":"Belt","values":["V","V"]},{"label":"Driveline","values":["Heavy duty with quick coupler","Heavy duty with quick coupler"]}]}]}
