Kubota KX080-3S Excavator

Models

KX080-3S

Kubota’s premium KX080-3S excavator features a 70HP DI engine and 3 pump load-sensing hydraulic system that powers through the harshest conditions. Work in the comfort of a luxury cab and feel peace of mind with clever features that ensure operator safety, increase productivity and keep operator costs to a minimum.

Related Categories

Construction

Excavators

Documents

Download Brochure KX080-3S Excavator Operator's Manual

No items found.

Features

Engine

Powered by a 66.6HP Kubota direct injection engine which is Tier IV compliant for reliability and to maximise digging and lifting performance. The engine has 3 opening bonnets to provide easy access for important daily check and to key components for servicing. The two-piece hose design for the dozer simplifies hose replacement and reduces downtime. Standard refuelling pump and hose to refuel. With a simple push of a button, tank fills with auto stop feature eliminating spillage.

Comfort

The KX080-3 offers a deluxe cab interior with superior comfort for long hours of operation, featuring suspension seat and ergonomically designed controls to reduce operator fatigue. Also, with a wider entrance for easy entry and exit from the cab along with greater operating area. The high-capacity dozer blade eliminates the need to separate machines for site prep, digging, and finish work, saving on money, time and staff.

Hydraulics

Kubota’s adjustable maximum oil flow control for auxiliary port allows the operator to control the oil flow according to need or the attachment in use, eliminating the hassle of using tools to change settings manually. And the unique hydraulic system ensures the smoothest operation regardless of load. Third line hydraulic return allows oil to flow back to tank without running through the control valves when working with one-way hydraulic attachments. This contributes to less oil contamination, reduced back pressure and greater oil flow efficiency.

Front Bush Pins

Bushings on all pivot points on the front attachment and connecting points on the swing bracket is one more feature that adds to the enviable durability of this machine.

Breakout Force

You need exceptional power when trenching through compacted soil. With the KX080-3S, elevated productivity levels are certain with the combination of 6,650 kg bucket force and 3,880 kg arm forces. The KX080-3S powers through those demanding applications so that you can quickly move on to the next job.

Auto Idling System

Save fuel with Kubota's Auto Idle. Reduce engine RPM instinctively when high engine speed isn’t needed. When the control levers are in neutral for more than 4 seconds, the engine RPM automatically idles. Move any control lever and the engine RPM immediately returns. This innovative feature reduces noise and exhaust emissions while reducing operating costs.

Safety

Anti-drop valve prevents an elevated load from dropping unexpectedly. Also, ROPS and FOPS certified for ease of mind when entering any job site. Overload alarm sensor alerts operator when load capacity has been exceeded, preventing possible injury or damage.

Key Specifications

{"version":1,"models":[{"code":"KX080-3S"}],"sections":[{"name":"Engine","rows":[{"label":"Engine Type","values":["Interim Tier 4 Emission Level"]},{"label":"Fuel Type","values":["Diesel"]},{"label":"Cylinders","values":["4"]},{"label":"Engine Model","values":["Kubota V3307DI-T"]},{"label":"Engine Net","values":["63.9 HP"]},{"label":"Engine Gross","values":["66.9 HP"]},{"label":"Displacement","values":["3331 cc"]},{"label":"Rated Speed","values":["2000 rpm"]}]},{"name":"Drive System","rows":[{"label":"Max. Traction Force","values":["6630 kgf"]},{"label":"Tumbler Distance","values":["2300 mm"]},{"label":"Crawler Length","values":["2900 mm"]},{"label":"Shoe Width","values":["450 mm"]},{"label":"Ground Contact Pressure - Canopy (Per cm2)","values":["0.367 kgf"]}]},{"name":"Hydraulics","rows":[{"label":"Hydraulic Pump Capacity","values":["72.0 variable x2 / 66.6 Gear x 1 l/min"]},{"label":"Aux Hydraulic Flow - AUX1","values":["100 l/min"]},{"label":"Aux Hydraulic Flow - AUX2","values":["66.6 l/min"]},{"label":"Max. Breakout Force - Bucket","values":["6650 kgf"]},{"label":"Max. Breakout Force - Arm","values":["3880 kgf"]}]},{"name":"Swing System","rows":[{"label":"Swing System","values":["Conventional Swing"]},{"label":"Unit Swing Speed","values":["9.5 rpm"]},{"label":"Boom Swing Angle Left","values":["70 degree"]},{"label":"Boom Swing Angle Right","values":["60 degree"]}]},{"name":"Travelling Speeds","rows":[{"label":"Low","values":["2.7 km/h"]},{"label":"High","values":["4.9 km/h"]}]},{"name":"Dimensions","rows":[{"label":"Length","values":["6450 mm"]},{"label":"Width","values":["2200 mm"]},{"label":"Height - Cab","values":["2540 mm"]},{"label":"Min. Ground Clearance","values":["390 mm"]},{"label":"Operating Weight - Rubber Inc. Operators Weight of 75kg","values":["8280 kg"]}]},{"name":"Blade","rows":[{"label":"Max. Blade Width","values":["2200 mm"]},{"label":"Blade Height","values":["500 mm"]},{"label":"Max. Lift Above Ground","values":["500 mm"]},{"label":"Max. Drop Below Ground","values":["500 mm"]}]},{"name":"Fluid Capacity","rows":[{"label":"Fuel Reservoir","values":["115 l"]},{"label":"Hydraulic Oil Reservoir","values":["75 l"]},{"label":"Hydraulic Oil System","values":["135 l"]},{"label":"Engine Oil","values":["10.7 l"]}]},{"name":"Safety Equipment","rows":[{"label":"Operator Station","values":["Cab"]},{"label":"Anti-Drop Valve - Boom","values":["YES"]}]},{"name":"Working Range","rows":[{"label":"Max. Digging Height","values":["7300 mm"]},{"label":"Max. Dumping Height","values":["5250 mm"]},{"label":"Max. Digging Depth","values":["4600 mm"]},{"label":"Max. Vertical Digging Depth","values":["3850 mm"]},{"label":"Max. Digging Radius At Ground","values":["7170 mm"]},{"label":"Max. Digging Radius","values":["7330 mm"]},{"label":"Min. Turning Radius - w/o Swing","values":["2490 mm"]},{"label":"Min. Turning Radius - Swing","values":["2000 mm"]},{"label":"Min. Tail Turning Radius","values":["1460 mm"]}]}]}
