Landscape Rake LR05 Series

Landscape Rake LR05 Series

Models
LR0548, LR0560

The Land Pride LR0548 & LR0560 Landscape Rakes are perfectly suited for light-duty use by landscapers and rental yards with applications at housing projects, golf courses, terracing sites, run-off control projects and restoration sites to perform final soil surface preparation and reshaping soil and/or aggregate profile. Optional dual gauge wheels are also available to enable a more consistent finish over uneven or undulating terrain.

Related Categories

Agriculture
Agriculture
:
Implements.
Lifestyle
Lifestyle
:
Implements
Contact Us

Documents

Download BrochureLR05 Landscape Rake Operator's Manual
Orange rake attachment with rows of steel tines.
Orange rake attachment with rows of steel tines on a white studio background.
No items found.

Features

QUICK HITCH COMPATIBLE

As all other Land Pride products, the LR05 Series is compatible with the Quick Hitch system.

HEAVY FRAME PLATE

Heavy frame plate adds durability.

TEETH

High carbon spring steel teeth have “memory” to spring back to shape and are sized to eliminate premature bending and tooth breakage.

EASY TOOTH REPLACEMENT

Teeth alignment secured by channel frame design allows easy single tooth replacement.

OPTIONAL GAUGE WHEELS

Optional gauge wheels provide ease of depth control.

Key Specifications

{"version":1,"models":[{"code":"LR0548"},{"code":"LR0560"}],"sections":[{"name":"Specifications","rows":[{"label":"Min. Horsepower","values":["15 hp","15 hp"]},{"label":"Max. Horsepower","values":["25 hp","25 hp"]},{"label":"Max. Angle","values":["30°","30°"]},{"label":"Max. Offset","values":["N/A","N/A"]},{"label":"No. of Teeth","values":["26","34"]},{"label":"Tooth Spacing – Centres","values":["44 mm","44 mm"]},{"label":"Tooth Material","values":["High Carbon Spring Steel","High Carbon Spring Steel"]},{"label":"Tooth Thickness","values":["6 mm","6 mm"]},{"label":"Tooth Width","values":["19 mm","19 mm"]},{"label":"Rake Height","values":["305 mm","305 mm"]}]},{"name":"Hitch","rows":[{"label":"Cat. I","values":["Yes","Yes"]},{"label":"Cat. II","values":["No","No"]},{"label":"Quick Hitch Compatible","values":["Yes","Yes"]}]},{"name":"Dimensions","rows":[{"label":"Working Width","values":["122 cm","152 cm"]},{"label":"Weight","values":["44 kg","51 kg"]}]}]}
