Landscape Rake LR26 Series

Landscape Rake LR26 Series

Models
LR2684, LR2696

Land Pride's LR26 Series Landscape Rakes are ideal for spreading rock, moving debris, preparing seed beds, and reshaping soil and/or aggregate profile. LR26 Rakes are available in 84" (LR2684) and 96" (LR2696) widths. These Landscape Rakes offer seven forward angles up to 45 degrees. The LR26 is designed for tractors up to 60 HP and features a quick-hitch compatible Cat. 1 Hitch and can be ordered with an optional hydraulic angling kit.

Related Categories

Agriculture
Agriculture
:
Implements.
Lifestyle
Lifestyle
:
Implements
Contact Us

Documents

Download BrochureLR26 landscape Rake Operator's Manual
Orange rake attachment with rows of steel tines.
Orange rake attachment with rows of steel tines on a white studio background.
No items found.

Features

QUICK-HITCH COMPATIBLE

Our Quick-Hitch System allows you to quickly connect and disconnect from the implement - most without leaving the tractor seat. This is a real time saver when working on multiple projects.

TEETH

High carbon spring steel teeth have “memory” to spring back to shape and are sized to eliminate premature bending and tooth breakage.

EASY TOOTH REPLACEMENT

Teeth alignment secured by channel frame design allows easy single tooth replacement.

HEAVY FRAME PLATE

Heavy frame plate adds durability.

OPTIONAL GAUGE WHEELS

Optional gauge wheels provide ease of depth control.

OPTIONAL HYDRAULIC ANGLING KIT

Allows the operator to change rake angle from the tractor seat.

Key Specifications

{"version":1,"models":[{"code":"LR2684"},{"code":"LR2696"}],"sections":[{"name":"Specifications","rows":[{"label":"Min. Horsepower","values":["25 hp","25 hp"]},{"label":"Max. Horsepower","values":["60 hp","60 hp"]},{"label":"Max. Angle","values":["45°","45°"]},{"label":"Max. Offset","values":["N/A","N/A"]},{"label":"No. of Teeth","values":["42","48"]},{"label":"Tooth Spacing – Centres","values":["50 mm","50 mm"]},{"label":"Tooth Material","values":["High Carbon Spring Steel","High Carbon Spring Steel"]},{"label":"Tooth Thickness","values":["8 mm","8 mm"]},{"label":"Tooth Width","values":["25 mm","25 mm"]},{"label":"Rake Height","values":["419 mm","419 mm"]}]},{"name":"Hitch","rows":[{"label":"Cat. I","values":["Yes","Yes"]},{"label":"Cat. II","values":["No","No"]},{"label":"Quick Hitch Compatible","values":["Yes","Yes"]}]},{"name":"Dimensions","rows":[{"label":"Working Width","values":["213 cm","244 cm"]},{"label":"Weight","values":["150 kg","158 kg"]}]}]}
