Landscape Rake LR37 Series

Landscape Rake LR37 Series

Models
LR3784, LR3796

Land Pride's LR3784 & LR3796 Landscape Rakes are perfectly suited for housing construction, road reconditioning, run-off control projects, and reforestation sites to spread rock, move debris, seed preparation, final soil surface preparation, and reshaping soil and/or aggregate profile.

Related Categories

Agriculture
Agriculture
:
Implements.
Lifestyle
Lifestyle
:
Implements
Contact Us

Documents

Download BrochureLR37 Landscape Rake Operator's Manual
Orange rake attachment with rows of steel tines.
Orange rake attachment with rows of steel tines on a white studio background.
No items found.

Features

QUICK-HITCH COMPATIBLE

Our Quick-Hitch System allows you to quickly connect and disconnect from the implement - most without leaving the tractor seat. This is a real time saver when working on multiple projects.

HEAVY FRAME PLATE

Heavy frame plate adds durability.

OPTIONAL GAUGE WHEELS

Optional gauge wheels provide ease of depth control.

OPTIONAL HYDRAULIC ANGLING KIT

Allows the operator to change rake angle from the tractor seat.

REAR BLADE ATTACHMENT

The rake assembly can be removed from the main frame and a Rear Blade attached to give the Land Pride Rake versatility

TEETH

High carbon spring steel teeth have “memory” to spring back to shape and are sized to eliminate premature bending and tooth breakage.

EASY TOOTH REPLACEMENT

Teeth alignment secured by channel frame design allows easy single tooth replacement.

Key Specifications

{"version":1,"models":[{"code":"LR3784"},{"code":"LR3796"}],"sections":[{"name":"Specifications","rows":[{"label":"Min. Horsepower","values":["30 hp","30 hp"]},{"label":"Max. Horsepower","values":["80 hp","80 hp"]},{"label":"Max. Angle","values":["30°","30°"]},{"label":"Max. Offset","values":["45°","45°"]},{"label":"No. of Teeth","values":["42","48"]},{"label":"Tooth Spacing – Centres","values":["50 mm","50 mm"]},{"label":"Tooth Material","values":["High Carbon Spring Steel","High Carbon Spring Steel"]},{"label":"Tooth Thickness","values":["8 mm","8 mm"]},{"label":"Tooth Width","values":["25 mm","25 mm"]},{"label":"Rake Height","values":["419 mm","419 mm"]}]},{"name":"Hitch","rows":[{"label":"Cat. I","values":["Yes","Yes"]},{"label":"Cat. II","values":["Yes","Yes"]},{"label":"Quick Hitch Compatible","values":["Yes","Yes"]}]},{"name":"Dimensions","rows":[{"label":"Working Width","values":["213 cm","244 cm"]},{"label":"Weight","values":["209 kg","219 kg"]}]}]}
