Post Hole Digger PD10/25/35 Series

Models

PD10, PD25, PD35

The PD10 Series Post Hole Digger is just right for Category 1 three-point attachment for subcompact utility tractors. This unit offers a 30" (76cm) auger length and a choice of 6", 9", & 12" auger flights with cast steel fishtail tips for quick piloting and faster hole starting. Homeowners, landscapers, and rental yards will find this unit very effective for occasional duty and for working and manoeuvring in tight spots. The PD25 Series Post Hole Diggers are the perfect fit for heavy-duty applications on nurseries, tree farms, landscapers, contractors, construction companies & farms. The PD25 Series is designed for Category 1 or 2 three-point attachment, offers a 48" (122cm) auger length, and a choice of 6", 9", 12", 15", 18" or 24" auger flights with cast steel fishtail tips. The Land Pride PD35 Series Post Hole Digger is designed to meet the industrial duty applications of landscapers, construction companies, nurseries, ranchers, and farmers. The PD35 is designed for Category 1 or 2 three-point attachment and offers a 48" (122cm) auger length and 9", 12", 15", 18" or 24" auger flights with cast steel fishtail tips. Accessories include a storage stand, hydraulic down pressure kit (requires selective control valve (SCV) on tractor) and auger extensions.

Related Categories

Documents

Download Brochure PD Post Hole Digger Operator's Manual Specifications & Capacities

No items found.

Features

Extensive range of augers

The PD10 is available with auger sizes from 6" (15.2cm) to 12" (30.5cm) at 30" (76.2cm) long. The PD25 & PD35 has auger options up to 18" (45.7cm) and 48" (1.22m) long. Auger flights are 6mm thick and have forged and individually replaceable teeth.

Driveline

CAT II shear bolt driveline on PD10 and CAT III on PD25/35

Gearbox warranty

3 year parts and labour warranty on PD10 gearbox. 5 years on PD25/35

Key Specifications

{"version":1,"models":[{"code":"PD10"},{"code":"PD25"},{"code":"PD35"}],"sections":[{"name":"Specifications","rows":[{"label":"Min. Horsepower","values":["15 hp","25 hp","30 hp"]},{"label":"Max. Horsepower","values":["30 hp","55 hp","75 hp"]},{"label":"Weight Without Auger","values":["54.4 kg","84.4 kg","105.7 kg"]},{"label":"Output Shaft","values":["2\" (5.1cm)","2\" (5.1cm)","2\" (5.1cm)"]},{"label":"Hitch - Cat I","values":["Yes","Yes","Yes"]},{"label":"Hitch - Cat II","values":["No","Yes","Yes"]},{"label":"Yoke - Tubing","values":["73 mm","73 mm","73 mm"]},{"label":"Boom - Tubing","values":["73 mm","89 mm","89 mm"]},{"label":"Max. PTO Speed","values":["300 rpm","300 rpm","300 rpm"]},{"label":"Driveline","values":["Shear Bolt","Shear Bolt","Shear Bolt"]},{"label":"Auger Length","values":["76.2 cm","122 cm","122 cm"]},{"label":"Min. Dirt Auger Sizes","values":["6\" (152mm)","6\" (152mm)","6\" (152mm)"]},{"label":"Max. Dirt Auger Sizes","values":["12\" (305mm)","18\" (457mm)","18\" (457mm)"]},{"label":"Min. Rock Auger Sizes","values":["N/A","6\" (152mm)","6\" (152mm)"]},{"label":"Max. Rock Auger Sizes","values":["N/A","18\" (457mm)","18\" (457mm)"]},{"label":"Auger Flight Thickness","values":["6.4 mm","6.4 mm","6.4 mm"]},{"label":"Short Auger Extension","values":["7\" (178mm)","7\" (178mm)","7\" (178mm)"]},{"label":"Long Auger Extension","values":["14\" (356mm)","14\" (356mm)","14\" (356mm)"]},{"label":"Optional Hydraulic Down Pressure Kit","values":["Yes","Yes","Yes"]},{"label":"Optional Storage Stand","values":["Yes","Yes","Yes"]},{"label":"Optional Alignment Handle","values":["Yes","Yes","Yes"]}]}]}
