Track Loader SVL65-2s

Models

SVL65-2s

Building on the proven performance and reliability of the SVL65‑2, the upgraded SVL65‑2s delivers enhanced technologies, improved operator comfort and refined efficiency to meet the demands of modern worksites. Retaining the compact versatility and durability that made the SVL65‑2 a trusted machine, the SVL65‑2s introduces thoughtful upgrades across power delivery, control responsiveness and operator-focused features. Designed for increased productivity and ease of operation, the SVL65‑2s sets a new benchmark in its class while maintaining the rugged dependability operators expect from the SVL series. Both the standard and high-flow models continue to maintain compatibility with our broad range of our SSV and SVL performance‑matched attachment options.

Related Categories

Construction

Track Loaders

No items found.

Features

Vertical Lift

This feature elevates the bucket to an impressive height of 3010 mm at the hinge pin, all while maintaining the SVL65-2s notably extended reach of 886 mm. The Standard Self-leveling Function ensures that the bucket or fork remains level without requiring manual angle adjustments during lifting. This function can be easily activated or deactivated with a simple switch click.

Technology

The SVL65-2s now offers a colour LCD touchscreen which shows a wide range of functions including Machine Status, Hydraulic Oil Temperature, Coolant Temperature, Fuel Level, Attachment Performance Monitor, AUX Pressure Level, DEF Level and is integrated with the Rear View Camera. Along with Keyless Engine Start and Bluetooth Radio.

Electronic Travel Torque Management

The Electronic Travel Torque Management System enables you to operate more efficiently.

The ECU continuously assesses the machine's load to enhance hydraulic pump performance, ensuring smoother operation that maintains engine functionality to complete tasks effectively.

Auto-Shift

The auto shift feature enables machines to navigate turns seamlessly. The ECU continuously observes the traction load. If the traction load increases during a turn, yet before the machine begins to lose traction, it automatically downshifts to enhance low-range torque. Once the traction load decreases, it automatically upshifts for higher speeds.

Highback Seat (Standard) & LED Work Lights (Front and Rear)

The SVL65-2S is equipped with a high back seat as standard, providing support for your body and reducing fatigue.

LED lights ensure outstanding visibility in dim lighting conditions.

Key Specifications

{"version":1,"models":[{"code":"SVL65-2s"}],"sections":[{"name":"Engine","rows":[{"label":"Engine Type","values":["Tier 4 Emission Level"]},{"label":"Fuel Type","values":["Diesel"]},{"label":"Cylinders","values":["4"]},{"label":"Engine Model","values":["Kubota V2607-CR-TE4"]},{"label":"Engine Net","values":["59.9 HP"]},{"label":"Engine Gross","values":["68.4 HP"]},{"label":"Displacement","values":["2615 cc"]},{"label":"Rated speed","values":["2600 rpm"]}]},{"name":"Undercarriage","rows":[{"label":"Track Width - Standard","values":["320 mm"]},{"label":"Track Width - Wide","values":["380 mm"]},{"label":"Ground pressure Cab - Standard Track","values":["5 psi"]},{"label":"Ground pressure Cab - Wide Track","values":["4.4 psi"]},{"label":"Track roller (per side)","values":["4"]},{"label":"Track Ground Contact Length","values":["1470 mm"]},{"label":"Traction Force","values":["3813 kgf"]},{"label":"Min. Ground Clearance","values":["233 mm"]}]},{"name":"Hydraulics","rows":[{"label":"Aux Hydraulic Flow - Standard","values":["65.8 l/min"]},{"label":"Aux Hydraulic Flow - High","values":["102.2 l/min"]},{"label":"Loader Hydraulic Pressure (Per cm2)","values":["229.4 kgf"]}]},{"name":"Loader Performance","rows":[{"label":"ROC - 35% Tipping Load","values":["953 kg"]},{"label":"Tipping Load","values":["2722 kg"]},{"label":"Breakout Force - Bucket","values":["2093 kg"]},{"label":"Breakout Force - Lift Arm","values":["1935 kg"]},{"label":"Lift Arm Path","values":["Vertical"]}]},{"name":"Travelling Speeds","rows":[{"label":"Low","values":["7.8 km/h"]},{"label":"High","values":["11.5 km/h"]}]},{"name":"Dimensions","rows":[{"label":"Length","values":["2725 mm"]},{"label":"Width - Standard Track","values":["1657 mm"]},{"label":"Width - Wide Track","values":["1717 mm"]},{"label":"Height","values":["2029 mm"]},{"label":"Operating Weight - Cab","values":["3915 kg"]}]},{"name":"Fluid Capacity","rows":[{"label":"Fuel Reservoir","values":["82 l"]},{"label":"Hydraulic System","values":["50 l"]},{"label":"Hydraulic Tank","values":["20.3 l"]}]},{"name":"Safety Equipment","rows":[{"label":"Cab","values":["YES"]},{"label":"Open Cab","values":["NO"]},{"label":"Front Sliding Window","values":["YES"]}]}]}
